Aircraft Wheel Cleaning System: The Ultimate Solution for Wheel Maintenance

Efficient and Eco-Friendly Aircraft Wheel Hub Cleaning

Are you in search of a cutting-edge cleaning solution for aircraft wheel hubs that can save time, boost productivity, and ensure impeccable cleanliness quality? Look no further! Introducing our Aircraft Wheel Cleaning System, the trusted choice of commercial airliners worldwide. Designed to handle up to 30 aircraft wheel hubs of any size within an 8-hour shift, this state-of-the-art system is engineered to meet the highest standards of performance, efficiency, and environmental responsibility.

Cutting-Edge Aqueous Cleaning Technology

Our Aircraft Wheel Cleaning System harnesses the latest aqueous cleaning technology to meticulously eliminate grease, rubber residues, dirt, and brake dust from wheel hubs. This thorough cleaning process is essential before inspection or overhaul. We prioritize environmentally friendly solutions, ensuring full compliance with stringent environmental regulations.

Innovative Cleaning Process

The base model of our system utilizes a recirculating, hot alkaline solution, which is sprayed onto the wheel at high pressure. This effectively removes oil, grease, and dirt. Simultaneously, a rotating brush scrubs the bead seat area of the wheel, eradicating accumulated rubber residues. The wheels are then rinsed with non-recirculated fresh water, with the spent water being responsibly diverted to drain. For enhanced cleaning, you can opt for our unique slurry blast stage, which is particularly effective for wheels fitted with carbon brakes.

Tailored to Your Needs

We understand that every operation is unique. To accommodate various requirements, our system offers customizable options such as automatic loading and unloading. You have the flexibility to configure the system to suit your specific needs, ensuring maximum efficiency and convenience.

Benefits for Your Service Department

  • By integrating our Aircraft Wheel Cleaning System into your workflow, your service department stands to gain numerous advantages:
  • Increased Productivity: Say goodbye to tedious manual cleaning and handling, and hello to improved productivity.
  • Uniform and Repeatable Quality: Achieve consistent, high cleanliness quality with every use.
  • Reduced Risk of Injury: Minimize the risk of workplace injuries associated with manual cleaning methods.

Features & Benefits

  • High-Pressure Cleaning: Our system delivers high-pressure cleaning at 150 psi+, effectively removing bearing grease and brake contamination.
  • Optional Slurry Blast Stage: Opt for this feature to ensure the effective removal of carbon deposits.
  • Rinse Stage: Remove detergent residue with ease using the automated freshwater rinse, which is activated after the wash stage. For higher production rates, a fully recirculated high-flow water rinse is available.
  • Rotating Brush: The rotating brush scrubs the bead seat area of the wheel, eliminating rubber deposits and facilitating more reliable NDT inspection.
  • Optional Auto Loader: Achieve unattended machine operation with the optional auto loader. Operators can select cleaning recipes for up to 20 wheel halves from a remote station.
  • PLC-Controlled: The machine and processes are PLC-controlled, allowing for up to 10 different cleaning recipes to be pre-stored.

Options

  • Recirculated rinse
  • Recirculated slurry blast and rinse stage
  • Automatic load and unload system
  • Stainless-steel pump, spray manifolds, exhaust blower and brush core
  • Special parts basket
  • Marine door on tank
  • Power supply other than standard 460V

Standard Features

  • Stainless-steel 304 construction
  • Three(3) universal-type wheel hub fixtures
  • Vertical sliding cabinet hood with safety latch
  • Recirculated wash
  • Freshwater rinse
  • Plant air blow-off
  • Two chip baskets accessible by a hinged tank cover
  • Rotating polypropylene brush
  • Programmable logic controller (PLC) with preprogrammed cleaning process
  • Stainless-steel disc-type oil skimmer
  • Exhaust blower
  • All moving parts are covered with safety guards
  • Automatic solution level control
  • Low solution level heating system protection
  • Electric solution heating
  • Fully insulated solution tank and hood
  • Low energy consumption design resulting in lower heating requirements
  • Vertical sealless pump
  • Maximum noise level of 80 dB(A)
  • Finish: two-component epoxy paint
  • Easy access to mechanical components
